Product

Oxyboss OB-H301

2.0 ATA Single Person Mini Hyperbaric Chamber

The OB-H301 mini hyperbaric chamber combines a rugged pressure vessel, a space-saving footprint, and a fully integrated oxygen source in one seated single person hyperbaric chamber built for home wellness rooms, boutique studios, and busy recovery centers.
2.0 ATA pressure90% oxygen concentration60 dB quiet operation
Adjustable operating pressure from 1.1 to 2.0 ATA. Third-generation 3-in-1 oxygen source with concentrator, air compressor, and air conditioner in a single cabinet. Sync touchscreens inside and outside the chamber, so the user runs the session without an outside operator.
  • 3-in-1 integrated oxygen source — one cabinet, one power cord
  • 1.1–2.0 ATA operating pressure, adjustable
  • Optional BIBS for advanced protocols
  • Front-opening or side-opening door, chosen at order
  • DDP door-to-door shipping — no surprise customs bill
  • 3-year global warranty on the chamber and the oxygen source
Placeholder 1440 x 680
Placeholder 1440 x 680
Placeholder 1440 x 680
Placeholder 1440 x 680

Integrated 3-in-1 Oxygen Source

Request a quote
Most home hyperbaric chambers on the market — including the ones people compare us with — ship as a chamber only. The oxygen concentrator, the air compressor, and the air conditioner are three separate boxes you’re expected to source, plumb, and maintain yourself. The OB-H301 skips all of that. Compression, oxygen generation, and interior climate control all live in one cabinet — Oxyboss’s third-generation 3-in-1 oxygen source, engineered for continuous operation.
Placeholder 24 x 24

Fully Modular Internals

Every core module inside the cabinet — PSA sieve, compressor, condenser, control board — is designed to be pulled and swapped individually. A single component failure doesn’t mean stripping the whole system. It means one part, one job.
Placeholder 24 x 24

Single-hose Plumbing

All lines between the oxygen source and the chamber are bundled into one integrated cable path. Setup is one connection. The room stays clean. No spaghetti of hoses across the floor.
Placeholder 24 x 24

0.42 m² Footprint

The 3-in-1 cabinet measures 930 × 450 × 920 mm — roughly the footprint of a small filing cabinet. Compared with the 0.9–1.2 m² of floor space that three separate units usually take up, the OB-H301 gives back most of a square meter. That matters when the chamber is going in a spare bedroom, a wellness studio corner, or a treatment room already crowded with other equipment.
Placeholder 24 x 24

PSA Molecular Sieve

Pressure swing adsorption delivers 90% ± 3% oxygen concentration at 10 L/min, continuously, for the entire session length. No cylinders to swap, no medical gas contract, no delivery schedule.
Placeholder 24 x 24

Oil-free Compressor

No oil vapor in the airflow path. Long-term maintenance is filter changes and seal inspections, nothing else.
Placeholder 24 x 24

Integrated Water-cooled Climate Control

Precise interior temperature control for longer sessions, especially in warm rooms.
Placeholder 24 x 24

Sound Damping

Six-sided sound-damping panels on the cabinet walls, plus vibration isolation springs under the compressor and concentrator bases. Outside the cabinet, 1 meter away, sound level is ≤ 60 dB(A) — about the volume of a normal conversation. Inside the chamber during a session, 45–48 dB(A) — quieter than a dishwasher.

1.4 m² projected footprint

The chamber measures 140 × 100 × 190 cm — about the floor space of a single-person massage chair, and low enough to slip into a room corner or a spa treatment nook without renovation. This is what makes the OB-H301 a genuine small hyperbaric chamber for tight spaces, not a marketing label.
The pressure vessel is Q235 industrial-grade carbon steel — chosen because it holds shape under repeated pressurization cycles day after day. In a home the chamber may run once a day; in a wellness studio it may run six times. The material spec is the same either way.
Two door orientations to fit different room layouts and use patterns. Choose at order.
The interior seat is upholstered in polyamide fabric — sweat-resistant, oil-resistant, alcohol-tolerant for cleaning between sessions. The cushions are modular, so a single worn panel can be swapped without replacing the whole seat.
The interior walls are lined with anti-static fiber to dissipate any static charge from clothing or movement — one of the mechanisms the FDA safety communication of August 2025 flagged as a fire risk factor in poorly designed chambers. (FDA safety communication on hyperbaric chamber fires)
The chamber has multiple external windows, so the interior stays bright and open. Users who worry about claustrophobia usually find the sit-down format significantly easier than a capsule.

Compact Chamber, No Compromise on The Experience

Chamber design decides both structural stability and how the user actually feels during a session. The OB-H301 is engineered around three principles: flexible deployment, straightforward daily operation, and long-run mechanical stability. It’s compact — but nothing about the interior experience is scaled down to get there.
Contact Us

Mirrored Controls, Inside And Outside

The OB-H301 has two synchronized 10-inch touchscreens — one mounted inside the chamber next to the user, one on the outside of the 3-in-1 cabinet. Both screens display the same real-time information and accept the same inputs:
  • Pressure setpoint and current pressure
  • Session timer
  • Interior temperature
  • Oxygen concentration
  • Alarm status

Every control lives on one screen. No nested menus, no submenu diving to change a setting. Training time is measured in minutes, not sessions.

The chamber also ships with a two-way intercom between the interior and exterior — used when someone else is running the equipment or when the user simply wants to talk without opening the door.

The practical outcome is that the user can operate a session solo. No dedicated technician needed on the outside.

Request a Quote

Passive Safety Design

The OB-H301’s safety features are designed to work without power. In an outage, a lightning strike, or a short circuit, purely mechanical mechanisms take over — 100% coverage, no electronic dependency.

Automatic pressure relief valve

Pure mechanical spring construction. When chamber pressure exceeds the setpoint, the valve opens and bleeds pressure until equilibrium is restored, then closes. The cycle repeats throughout the session — that’s how the chamber holds a stable target pressure.

Manual pressure regulator

A tactile fine-adjustment knob for user-controlled pressure changes during the session.

Emergency pressure release

A single-action release opens a large-diameter vent for rapid depressurization in 30–60 seconds. Both interior and exterior control locations.

Self-locking pressure door

The chamber door uses interior pressure to hold itself sealed — the higher the pressure, the tighter the seal. When pressure fully vents to ambient, the door releases and can be opened by hand from either side.

Fire-retardant, anti-static interior

No exposed electrical components inside the chamber. Anti-static flooring throughout.
The chamber pressurizes with compressed air, not oxygen — chamber interior air stays close to normal room oxygen concentration. The 90% ± 3% oxygen flows through the mask or nasal cannula only, delivered directly to the user’s breathing zone. This is the single most important safety design difference between a well-engineered mild hyperbaric chamber and the incident cases the FDA has reported.

Why Choose Oxyboss

Oxyboss has manufactured hyperbaric chambers for 20+ years and ships to buyers in 130+ countries and regions — wellness operators, medical resellers, and individual home users. Here’s what that experience means for your order.

Full system, one purchase

Every hard-shell Oxyboss chamber ships with the 3-in-1 oxygen source as standard, not as a paid add-on. The price you get from us is the price of a running system. There’s no line-item creep for the concentrator, the compressor, or the AC unit.

DDP door-to-door shipping

We handle transport, customs clearance, and all import duties. You don’t get a customs broker calling three weeks after delivery asking for another payment. Typical transit is 35–45 days to the contiguous US by sea, 45–55 days to Europe by sea, or 15–20 days worldwide by air.

Pre-shipment transparency

Before your OB-H301 leaves the factory, we send you photos and a video walk-around of the actual unit, plus test video of five factory acceptance checks: pressure hold and leak, oxygen concentration verification (must land inside 90% ± 3%), compressor and AC function, touchscreen sync, and all three voltage settings powered up. If you want an independent inspection agency (SGS, Bureau Veritas, TÜV) verifying before shipment, we accommodate that — inspection cost is on the buyer.

3-year warranty

Global. Same terms in the US as in Europe as in Southeast Asia. Consumables (mask, mattress, pillow, soft padding, seals) aren’t covered — they’re wear parts by design.

Fast fault response

Report an issue with photo or video, our engineers confirm the fault within 48 hours, and any needed replacement modules ship within 3–5 days — by air, at our cost during warranty. 24/7 online technical support for the life of the chamber.

Certifications you can verify

CE / PED certificate 10.07.12722, issued by EUROCERT S.A. (Notified Body 1128), Module H, valid through 2029-08-09. ISO 9001 certificate 11726Q2286R002 in the CNAS-accredited scheme. ISO 13485. Full documentation available on request; every export shipment includes a complete customs pack.

OEM, private label, and dealer support

Custom logo, custom color, and private label are available with no additional customization fee. Dealer pricing starts at 2 units. Regional exclusivity and MAP protection are available on qualified partnerships.

What's Included in Every OB-H301

Every OB-H301 order ships as a complete, ready-to-run system. Nothing else needs to be purchased separately.

Optional add-ons: BIBS system, 20 L concentrator upgrade for extended sessions, custom logo, custom color, extended hose kit.
Contact Us
  • The chamber — pre-assembled at the factory, ready to place
  • The 3-in-1 oxygen source cabinet — concentrator, compressor, air conditioner in one unit
  • Plug-and-play cabling between the chamber and the oxygen source (standard length, extendable to 5–7 m on request)
  • Pre-shipment video walk-around of your specific unit before it leaves the warehouse
  • Interior modular PA sofa with anti-static lining
  • One-on-one online video training session with a factory technician (training certificate available on request)
  • Interior and exterior 10-inch synchronized touchscreens
  • Two-way interior/exterior intercom
  • Oxygen mask and consumables for first-session setup

Ideal Use Cases

The OB-H301 is designed for buyers who need a single person hyperbaric chamber that:
  • Fits into a spare bedroom, home office, or wellness room without renovation
  • Runs on standard 110V / 220V / 240V outlets — no special electrical work
  • Sits up rather than lies down — for reading, tablet use, or working during a session
  • Handles daily use over 8–10 years of expected service life
  • Works for both a private home and a small commercial wellness or recovery studio

Common deployment scenarios: home wellness rooms, boutique recovery studios, SPA and salon back-of-house, gym add-on services, dealer showrooms.

If you need a two-person seat, the H402 double shell or D201 cylinder are the closer fit. If you need to fold the chamber away between uses, look at the S158 or S159 soft-shell instead.

Contact Us

Full Technical Specifications

Learn More

Chamber Parameters

ModelOB-H301
TypeHard-shell single person sitting chamber
Maximum operating pressure2.0 ATA
Adjustable pressure range1.1–2.0 ATA
Chamber materialQ235 carbon steel
Chamber dimensions (L × H × W)140 × 100 × 190 cm
Chamber weight600 kg
DoorFront-opening or side-opening (specify at order)
Operating noise≈60 dB
Current110 / 220 / 240 V
IntercomTwo-way, interior ↔ exterior
Oxygen source3-in-1 integrated: 10 L concentrator + air compressor + air conditioner
Concentrator dimensions930 × 450 × 920 mm
Concentrator weight130 kg
Oxygen concentration90% ±3%
Oxygen flow rate10 L/min
Current draw10 A
System power2200 W
BIBS optionAvailable
Energy use~2.2 kWh per hour of operation
Session lengthUp to 2 hours per session, 20–30 minute rest between sessions
Warranty3 years on chamber and oxygen source, global

Certified Quality,
Carefully Inspected

All materials are verified eco-friendly and non-toxic. Free from harmful substances. Each unit passes strict quality inspection before leaving the facility, including pressure integrity testing, electrical safety verification, seal performance confirmation, and oxygen system calibration.
View Certificate
CEEuropean safety and performance conformity
ISO 9001Soft triangular hyperbaric oxygen chamber
ISO 13485Quality management for health technology manufacturing
SGS TestingIndependent third-party material and performance verification
Contact

Get a Quote for The OB-H301

We don’t publish prices online because they depend on your country, shipping method, voltage, and configuration. Send us your requirements and we’ll come back with an all-in DDP quote within one business day.

Tell us:

  • Your country and city
  • Voltage (110V / 220V / 240V)
  • Door orientation (front-opening or side-opening)
  • Any upgrades (BIBS, 20 L concentrator, custom logo, custom color, extended hose)
  • For dealers: expected annual volume
FAQ

OB-H301 Questions

The OB-H301 is a mini hyperbaric chamber — 140 × 100 × 190 cm, 1.4 m² footprint. Small enough to fit a spare room, structurally rated for the full 1.1–2.0 ATA operating range.

Two different product classes. Inflatable soft-shell chambers cap out at 1.5 ATA, weigh 18–24 kg, and fold down for storage. The OB-H301 is a hard-shell chamber — Q235 carbon steel pressure vessel, 600 kg, 2.0 ATA ceiling, designed for permanent installation and long-term daily operation.

No. We sell as a personal wellness device, not a medical device. That said — see “Who shouldn’t use one” below, and talk to your physician if anything on that list applies to you. The fact that we don’t require a prescription doesn’t mean the safety list doesn’t matter.

No. Clinical monoplace chambers pressurize the entire interior with 100% oxygen at 2.0–3.0 ATA, cost $94,000+, and are used in hospitals under a trained technician. The OB-H301 pressurizes with compressed air, delivers 90% oxygen through a mask, and is designed for home and small commercial wellness use. Different product class.

The chamber itself occupies 1.4 m². The 3-in-1 oxygen source adds another 0.42 m². Total footprint about 1.9 m², plus 50 cm of clearance above the chamber for ventilation and access to the relief valve. Ceiling height 200 cm minimum, 210 cm recommended.

The chamber ships as a single assembled unit. Front-to-back it’s 140 cm; you’ll need a doorway at least 105 cm wide to clear the 100 cm chamber body plus handling clearance. Measure your doorways, hallway turns, and any stair corners before ordering — we can send exact packaged dimensions and weight for your route.

The chamber and oxygen source together draw about 2.2 kWh per hour of operation. At the 2026 US residential average of about $0.17/kWh, that’s roughly $0.37 per hour. Add periodic consumables (filter, door seal, sieve) and you’re looking at low-double-digit dollars per month for daily home use.

Talk to your physician before your first session if any of the following applies:

  • Ear problems (perforated eardrum, ear tubes, middle-ear surgery, difficulty equalizing pressure)
  • A cold, sinus infection, or active allergies
  • Lung conditions (history of collapsed lung, COPD, emphysema, uncontrolled asthma, recent chest surgery)
  • Heart or blood vessel conditions (uncontrolled high blood pressure, heart failure, recent heart attack, arrhythmia)
  • History of seizures
  • Recent eye surgery, especially procedures using a gas bubble
  • Pregnancy
  • An implanted pacemaker or neurostimulator (check with the device manufacturer first)
  • Severe claustrophobia
  • Under 18 (should only be used under physician guidance and adult supervision)
  • Currently unwell, dehydrated, or under the influence of alcohol or sedatives
  • Taking medication that may interact with elevated pressure or oxygen

If any of this applies, don’t guess — ask your doctor. Consult a physician before your first session. Not needing a prescription is about product classification, not about whether this list matters. It matters.

get started

Find the Right Chamber for Your Life

The best model is the one that fits your space, your body, and your daily rhythm. Whether you’re exploring hyperbaric wellness for the first time or looking for a specific chamber format, the Oxyboss team is here with clear recommendations and honest comparisons.
Get a Personalized Recommendation
